A Core Solution for Coking Energy Efficiency Enhancement and Low-Carbon Emission Transformation

Coke Dry Quenching (CDQ) technology is a key process for the coking industry to achieve efficient energy recovery and clean power generation. This technology recovers sensible heat from red-hot coke at approximately 1,000℃ through an inert gas circulation system, converting it into medium to ultra-high temperature and pressure superheated steam. By integrating steam reheating technology, it drives turbine generator units to deliver stable power generation and heat supply, significantly improving energy utilization efficiency.

Technical Advantages

lEfficient Energy Recovery

Steam production rate of approximately 500–650 kg/ton of coke

Power generation of approximately 150–190 kWh/ton of coke

lLarge-Scale Application

Single unit power generation capacity ranging from 3,000–50,000 kW, adaptable to coking enterprises of various scales

lWorld-leading References

Successfully delivered over 270 units worldwide, with total installed capacity exceeding 3000 MW
